Page 4

1300

3 HOW TO ASSEMBLE

INSTALLATION OF THE
TURNTABLE PLATTER

install the turntable platter to the motor shaft.

Place the turntable sheet on the turntable platter.

NOTE

This set is especially designed tor a direct drive player system.
Therefore. the rotor. which is rotating part of the motor. is con-
nected directly to the turntable platter. (The magnet oi the motor
is attached to the turntable platter).

For this reason. to maintain the high periormance described in
the speciiications. care should be taken to prevent any dust or
iron iilings irom getting into and adhering to the magnet. Also
avoid dropping the turntable platter onto a hard surlace. as this
may break the magnet.

INSTALLATION OF THE CARTRIDGE

Connect the lead wires to the cartridge terminals.
White (L +)..Lett channel + Red (R +).. Right channel +
Blue (L -) ..Leit channel - Green (R -) Right channel -

Overhang adjustment

screw ' ’ “
—— a l ‘ x‘ }
Washer .—-—--s ‘ . 1 ‘ , f Head shell
,9. n - “Kit, ,
-/‘.{,;- ~~ .
v 1

Shell spacer

1:] Screws

1 '1 Fly. 2

Install the cartridge to the spacer. and tighten it with screws.
Adjust the overhang position so that the spacing between the
stylus tip and the plug is 52 mm (2-1/16'). (See Fig. 2. 3)

Insert the head shell in the end of the tonearm. and secure iirmly
by turning the locking nut. New developments for nsm design water supply system.

Overhang adlustment screw Plug

Stylus tIp

52 mm (2-1/1s')————~(
S — I/I

ADJUSTMENT OF THE
HORIZONTAL BALANCE

Insert the balance weight on the rear shalt oi the tonearm by
turning the balance weight.

Release the arm clamp. and turn the balance weight iorward or
backward until the tonearm is approximately balanced (stylus
pressure is “0'). (See Fig. 4)

When horizontally balanced. set the stylus pressure ring to ”0'
position. pushing gently with lingers. so that the balance weight
is not moved. (See Fig. 5)

Fig. 3

(3

Turn the balance weight iorward to set the stylus pressure ring
to the proper stylus pressure at which you use.

Technics Sl-1300 Turntable Manual

NOTE

It the weight oi the cartridge is over 8.59. mount the auxiliary
weight to the rear shait oi the tonearm.

Stylus pressure ring moves to gear with balance weight so that
it is possible to set the stylus pressure ring tothe desired position
by turning the balance weight.

Arm rest Balance weight

Technics sl 1300 turntable service manual

Arm clamp

Technics Sl 1300 For Sale

Cuelng lever

. 7

ADJUSTMENT OF THE
ANTI-SKATING FORCE

Turn this knob to the same number as the stylus pressure.

INSTALLATION OF THE DUST
COVER

Raise the dust cover upward and place it securely in the hinges.
NOTE (See Fig. 6)
We recommend that you take oti the dust cover. it the dust cover
becomes the cause at 'BOWLING' irom the vibration at the
speakers.

Dust cover

Hinge

Fig. 6
