  • Standard with 530 employees (Expandable)
  • Direct communication (50' RS232 Serial Cable Included)
  • Programmable keys job costing/job transfer

HP3000 HandPunch 3000 Terminal The HandPunch 3000 verifies the employee's identity in less than one second. Buddy punching and time fraud are eliminated, thereby reducing payroll costs. Verifies up to 512 employees (Expandable to 32,512). Schlage HandPunch 3000/4000 user guide PDF. Hp3-4-manual.pdf (2 MB) Was this article helpful? 0 out of 0 found this helpful. Have more questions? Submit a request.

SCHLAGE HANDPUNCH 3000 BIOMETRIC TIME CLOCK! Manufacturer's Schlage Biometric HandPunch 3000 RS232/485 Terminal- Includes 50' RS232 Cable! Refurbished HP-3000 Includes-Back plate-Power supply-50' RS232 Cable(Direct Connect) Bolts-1 Key Please Note: Software is Not Included in this listing. Schlage Electronics. 30 Minute Lunch Punch/Break Compliant - Enabling Lunch Out Function Key for HP XL readers. Resolution: The biometric F-series HandPunch 3000-XL, the HandPunch 3000-E-XL, and the HandPunch 4000 are all 'Break Compliant' hand reader models. Each of these hand readers utilizes an Extended Us. The Schlage HandPunch® 3000-E now brings the accuracy and convenience of biometric technology easily within reach of any time and attendance applications. With a HandPunch employees can clock-in for work without the use of cards.

Schlage HandPunch 4000 brings you the most effective solutions for employee time attendance and workforce management. The Schlage Biometric HandPunch 4000 time clocks are equipped with hand geometry technology. Every time the employee places their hand into the HandPunch 4000 terminal, the camera takes a 3 dimensional scan of the length, width and height. It then turns the image into an algorithm and saves it for future verification.

Schlage Recognition System - HandPunch 4000

What Does The Package Include?

  • HandPunch 4000 Biometric Hand Reader (530 Users, Expandable)
  • 50ft communication cable
  • Power transformer
  • Wall mount
  • Hardware Manual
  • One-year warranty

Schlage HandPunch 4000

When You Want To Cut Time And Attendance Costs..Do It By Hand

Schlage Biometrics brings the convenience and accuracy of biometric technology easily within grasp of any time and attendance application with the HandPunch 4000. In industry’s that range from clean rooms to coal mines, the Schlage biometric HandPunch 4000 time clock has proven itself to be a precise and practical solution for time management and access control.

Our Biometric Time Clock, Hand Scanner, Works By Identifying Employees' Hand Geometry Instantly

With the use of Schlage HandPunch 4000, employees are identified by the unique shape and size of their hand. This means your staff will no longer have the need to carry keys or cards for clocking IN or OUT. The risks and costs that come from lost, stolen or duplicates without authorization are eliminated. The HandPunch 4000 from Schlage also eliminates time fraud, making it literally impossible to “buddy punch”. This solution results in more accuracy, productivity and profitability for you company.

Your Hand Is Your Card

With AMG Technology’s biometric HandPunch 4000 time clock, there are no cards to administer, create, carry or lose. For mid-size companies, the HandPunch 4000 time attendance system will provide a substantial return on your investment by eliminating the cost associated with the management of administering cards. For companies with small multiple locations, or minimal supervision the likelihood of time theft due to buddy punching can be a real issue. With the Schlage Biometric HandPunch 4000 time clock it is impossible for an employee to clock-in or clock-out for the other. Time fraud is eliminated thereby decreasing payroll costs and positively impacting your company’s bottom line.

Communications

AMG HandPunch 4000 recognition system comes standard with RS232 connectivity, allowing for quick integration into your existing network infrastructure and time management systems. As an additional option you can upgrade to Ethernet (TCP/IP) as well.

Hand Geometry Technology

With proven biometric technology for hand geometry, the Biometric HandPunch 4000 time clock from Schlage, captures an image of the hand each time an employee clocks-in or clocks-out. The hands shape and size is used to verify their identity with amazing accuracy. No palm prints or fingerprints are utilized. The technology works well in harsh environments as well as indoors.

Programmable For Your Needs – Ten user-definable data managementoptions let you collect and/or display data as employees punch in, such as Department Transfers, Tips Collected, Job Codes or Pay Codes. The biometric time clock may also be used to allow employees to review clock-ins and clock-outs, vacation time accumulated, job schedules, hours worked and more.

Manage Schedules By Employee – Individual employee schedules may be downloaded to the HandPunch 4000 to restrict the times that an employee can punch, reducing unauthorized overtime.
Built-In Bar Code Reader – When a badge is required for identification, the biometric the HandPunch 4000 time clock is available with an integrated bar code reader. The swipe-style reader supports the most poplar bar code formats and allows for infrared badges.

Antimicrobial Protection

Biometric hand readers like the HandPunch 4000 comes with a silver based anti-microbial agent which is integrated into the materials used to replicate the platen. This provides a finish that inhibits the growth of bacteria, mold and fungi. This remains active for the life of the HandPunch terminal.

Hand Outline

The HandPunch 4000 includes a blue outline of a hand printed on the platen. This hand outlines is provided to assist new users in placing their hand accurately on the clocks platform thus decreasing initial enrollment time and better enrollment quality.

HandPunch 4000 Biometric Hand Reader Main Features:

  • 530 employees/user (Expandable to 51,516)
  • Two programmable function keys.
  • Saves money over card-based systems.
  • Eliminates badges.
  • Eliminates Buddy Punching.
  • Signal Bell and Access Control Relay
  • Provides the most accurate time and attendance solution available.

HandPunch 4000 Biometric Hand Reader Specifications:

  • Size: 8.85 in (22.3 cm) wide, 11.65 in (29.6 cm) high, 8.55 in (21.7 cm) deep.
  • Weight: 6 lbs (2.7 kg).
  • Power: 12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts.
  • Operating: 32°F to 113°F (0°C to 45°C)
  • Relative Humidity: 20% to 80% NC
  • Non-operating (storage): 14°F to 140°F (-10°C to 60°C)
  • Relative Humidity: 5% to 85% NC.
  • Verification Time: Less than one second.
  • Memory Retention: Up to 5 years via the standard internal lithium battery.
  • Transaction Storage: 7680 transactions.
  • ID Number Length: 1 to 10 digits from keypad or card.
  • User Capacity: 530 users (Expandable to 3,498 and 51,516)
  • Template Size: 9 bytes.
  • Communications: RS232
  • Baud Rate: 300 to 28.8 Kbps.
  • Employee Messaging: 32 Character per message per employee
  • Employee Name: 16 Characters
  • Baud Rate: 300 to 28.8 Kbps.

Hardware Requirements

Schlage handpunch 3000 manual
  • Power Source

Replacement Parts

Schlage Biometric HandPunch Clock Key HP-Key

Schlage Biometric HandPunch HP-Key works with all F-series Hand Readers. Key for HandPunch 1000, 1000E, 2000, 2000E, 3000, 3000E, 4000, 4000E

Accessories

HandPunch RS232 Serial Cable

The Schlage 50 Foot RS232 serial communication cable is compatible with serial connection HandPunch time clocks.

Communication Options

HandPunch Ethernet Communication Card EN-201

HandPunch F-Series Ethernet Communication Card/Module 10baseT.

Accessories

HandPunch Battery Backup - Initial Purchase

HandPunch battery backup available only at the time of initial purchase.

Schlage Handpunch 3000 Manualanimationsupport

Replacement Parts

HandPunch F-Series Platens Sticker

Schlage F-Series bottom plate Biometric HandPunch antimicrobial platen stickers with blue hand print outline. Click here to learn more!

Complete Platen Assembly with antimicrobial and blue hand outline

The F-Series HandPunch contains a silver based antimicrobial platen embedded into the finish that inhibits the growth of bacteria, mold or fungi.

Rubber Keypad for Schlage HandPunch

The rubber keypad for HandPunch F-Series time clocks constructed from strong lightweight silicon rubber seals against outside elements

Memory Options

EM-805 HandPunch HP-3000-XL & HP-4000 Memory Expansion to 3,498 users

Schlage EM-805 HandPunch HP-3000-XL & HP-4000 Memory Expansion to 3498 users.

EM-809 HandPunch HP-3000-XL & HP-4000 Memory Expansion to 5,141 users

Schlage EM-809 HandPunch HP-3000-XL & HP-4000 Memory Expansion to 5141 users.

Communication Options

HandPunch F-Series Modem MD-500

HandPunch internal 14.4K Baud Dial-up Modem.

Refurbished HandPunch F-Series Modem MD-500

HandPunch internal 14.4K Baud Dial-up Modem.

Card Reader & Keypad Options

HandPunch Option Externally Mounted HID ProxPoint RF Reader

Externally mounted HID ProxPoint RF Reader for HandPunch F-Series.

HandPunch Option SC-100 Mifare Smart Card Reader

Integrated side mounted Mifare smart card reader with external clear acrylic card holder.

HandPunch Option iClass Reader

Internally installed iClass reader with external clear acrylic card reader.

Enclosures

Schlage HandPunch Enclosure F-Series TX-ENCL TSNAMI

Schlage HandPunch Enclosure TX-Enclosure Tsunami for F-Series.

Schlage HandPunch Enclosure F-Series FX-ENCL Hurricane

Schlage HandPunch Enclosure FX-Enclosure for F-Series.

Accessories

HandPunch Power Supply PS-110 120 VAC to 13.5 VDC

HandPunch Power Supply 120 VAC to 13.5 VDC with connector.

HandPunch Power Supply (European) PS-220 220 VAC to 13.5 VDC

HandPunch Power Supply 220 VAC to 13.5 VDC with connector. (European)

HandPunch Power Supply (United Kingdom) PS-220 220 VAC to 13.5 VDC

HandPunch Power Supply 220 VAC to 13.5 VDC with connector. (United Kingdom)

Bell 110 Volt

Bell 110 Volt

Bell 24 Volt

Handpunch 3000 Calibration

Bell 24 Volt

Bell 24V Power Supply

Power Supply Transformer for Bell

HandPunch Relay

5v Bell Relay for HandPunch models HP3000 and HP4000.

Replacement Parts

HandPunch Top Panel Assembly for HP-4000

Replacement Part HandPunch Top Panel Assembly for HP-4000

Refurbished HandPunch Top Panel Assembly for HP-4000

Replacement Part HandPunch Top Panel Assembly for HP-4000

HandPunch Main Board for HP-4000

Replacement Part HandPunch Main Board for HP-4000

Refurbished HandPunch Main Board for HP-4000

Replacement Part HandPunch Main Board for HP-4000

HandPunch HP-4000 Overlay

Schlage HandPunch HP-4000 Overlay. Simply change your hand reader's overlay to keep its new look.

HandPunch Back Plate Wall Mounting Bracket for HandPunch Terminals

HandPunch back plate for all F-series Schlage HandPunch terminals. Many in stock, call or order online!

Refurbished HandPunch Back Plate Wall Mounting Bracket for HandPunch Terminals

HandPunch back plate for all F-series Schlage HandPunch terminals. Many in stock, call or order online!

  • Standard with 50 employees (Expandable to 100 & 512)
  • Direct communication (50' RS-232 Serial Cable Included)
  • Hand geometry technology

Schlage HandPunch 1000 brings you the most effective solutions for employee time attendance and workforce management. The Schlage Biometric HandPunch terminals are equipped with hand geometry technology. Every time the employee places their hand into the HandPunch 1000 reader, the camera takes a three dimensional scan of the length, width and height. It then turns the image into an algorithm and saves it for future verification.

Schlage HandPunch 1000

What does the Package include?

  • HandPunch 1000 Biometric Hand Reader (50 Users, Expandable to 100 and 512)
  • 50ft communication cable
  • Power transformer
  • Wall mount
  • Hardware Manual
  • One-year warranty
  • 2 Keys Included

Schlage Biometric HandPunch 1000

Schlage Handpunch 3000 Manual

When you want to cut time and attendance costs.. do it by hand

Schlage biometric recognition brings the accuracy and convenience of biometric technology easily within reach of any time and attendance application with the HandPunch 1000. In operations that range from coal mines to clean rooms, the Schlage HandPunch 1000 has proven itself to be a practical and precise solution for employee time management and access control.

Our Biometric Time Clock, Hand Scanner, Works by Identifying Employees' Hand Geometry Instantly

Schlage biometric systems identifies the employees by the unique size and shape of their hand. This means your employees will no longer need to carry cards or keys. The costs and risks associated with credentials that can be lost, stolen or duplicated without authorization is also eliminated. Schlage Recognition Systems also eliminates time fraud by making it virtually impossible to “buddy punch.” The result is more accuracy, productivity and profitability for your company.

Your Hand Is Your Card

With AMG's biometric recognition time clock the HandPunch 1000; there are no cards to create, administer, carry – or lose. For mid-size companies, the hand geometry reader provides a high return on investment by eliminating the cost associated with administering and managing cards. For companies that have single or multiple locations and face the daily occurrence of buddy punching, the Schlage Hand Reader 1000 will eliminate employee time theft instantly.

RS-232 Communication

Recognition Systems HandPunch 1000 comes standard with serial RS232 connection allowing for quick integration into your time management systems, applications and existing network infrastructure.

Hand Geometry Technology

The biometric time clock uses Schlage’s field-proven hand geometry biometric technology. The terminal captures an image of the hand each time the employee punches. The hand’s size and the shape are used to verify their identity with unparalleled accuracy. No fingerprints or palm prints are taken. The technology works well indoor as well as in harsh environments.

Antimicrobial Protection

Every biometric hand reader contains a silver-based anti-microbial agent-which is embedded into the materials used to produce the platen, providing a finish that inhibits the growth of a broad spectrum of bacteria, mold, and fungi and remains active for the life of the HandPunch.

Hand Outline

The HandPunch 1000 comes standard with a blue hand outline printed on the platen. This hand outline helps new users place their hand accurately on the platen thus decreasing initial enrollment time and better enrollment quality. It also includes the Ingersoll Rand Schlage Biometrics logo.

HandPunch 1000 Biometric Hand Reader Main Features

  • Saves money over card-based systems.
  • Eliminates Badges.
  • Eliminates Buddy Punching.
  • Fast and easy to use.
  • Provides the most accurate time and attendance solution available.

Ingersoll Rand HandPunch 1000 Biometric Hand Reader Specifications:

  • Size: 8.85 in (22.3 cm) wide, 11.65 in (29.6 cm) high, 8.55 in (21.7 cm) deep.
  • Weight: 6 lbs (2.7 kg).
  • Power: 12 to 24 VDC or 12 to 24 VAC 50-60 Hz, 7 watts.
  • Operating: 32°F to 113°F (0°C to 45°C)
  • Relative Humidity: 20% to 80% NC
  • Non-operating (storage): 14°F to 140°F (-10°C to 60°C)
  • Relative Humidity: 5% to 85% NC.
  • Verification Time: Less than one second.
  • Memory Retention: Up to 5 years via the standard internal lithium battery.
  • Ttransaction Storage: 5120 transactions.
  • ID Number Length: 1 to 10 digits from keypad or card.
  • User Capacity: 50 users expandable to 512 users.
  • Template Size: 9 bytes.
  • Communications: RS-232, 50 foot cable included.
  • Baud Rate: 300 to 28.8 Kbps.

Hardware Requirements

  • Power Source

Memory Options

EM-701 HandPunch HP-1000 Memory Expansion from 50 to 100 users

Schlage EM-701 HandPunch HP-1000 Memory Expansion from 50 to 100 users.

EM-702 HandPunch HP-1000 Memory Expansion from 50 to 512 users

Schlage EM-702 HandPunch HP-1000 Memory Expansion from 50 to 512 users.

EM-703 HandPunch HP-1000 Memory Expansion from 100 to 512 users

Schlage EM-703 HandPunch HP-1000 Memory Expansion from 100 to 512 users.

Communication Options

HandPunch F-Series Modem MD-500

HandPunch internal 14.4K Baud Dial-up Modem.

Refurbished HandPunch F-Series Modem MD-500

HandPunch internal 14.4K Baud Dial-up Modem.

Card Reader & Keypad Options

HandPunch Option Externally Mounted HID ProxPoint RF Reader

Externally mounted HID ProxPoint RF Reader for HandPunch F-Series.

HandPunch Option SC-100 Mifare Smart Card Reader

Integrated side mounted Mifare smart card reader with external clear acrylic card holder.

HandPunch Option iClass Reader

Internally installed iClass reader with external clear acrylic card reader.

Enclosures

Schlage HandPunch Enclosure F-Series TX-ENCL TSNAMI

Schlage HandPunch Enclosure TX-Enclosure Tsunami for F-Series.

HandPunch Weather Resistant Enclosure

Weather resistant HandPunch enclosure to protect against the rain, wind, and dust. Ideal for hostile environments to ensure safe keeping of your investment.

Schlage HandPunch Enclosure F-Series FX-ENCL Hurricane

Schlage HandPunch Enclosure FX-Enclosure for F-Series.

Accessories

HandPunch Power Supply PS-110 120 VAC to 13.5 VDC

HandPunch Power Supply 120 VAC to 13.5 VDC with connector.

HandPunch Power Supply (European) PS-220 220 VAC to 13.5 VDC

HandPunch Power Supply 220 VAC to 13.5 VDC with connector. (European)

HandPunch Power Supply (United Kingdom) PS-220 220 VAC to 13.5 VDC

HandPunch Power Supply 220 VAC to 13.5 VDC with connector. (United Kingdom)

HandPunch RS232 Serial Cable

The Schlage 50 Foot RS232 serial communication cable is compatible with serial connection HandPunch time clocks.

HandPunch Battery Backup - Initial Purchase

HandPunch battery backup available only at the time of initial purchase.

Replacement Parts

HandPunch F-Series Platens Sticker

Schlage F-Series bottom plate Biometric HandPunch antimicrobial platen stickers with blue hand print outline. Click here to learn more!

Schlage Biometric HandPunch Clock Key HP-Key

Schlage Biometric HandPunch HP-Key works with all F-series Hand Readers. Key for HandPunch 1000, 1000E, 2000, 2000E, 3000, 3000E, 4000, 4000E

Complete Platen Assembly with antimicrobial and blue hand outline

The F-Series HandPunch contains a silver based antimicrobial platen embedded into the finish that inhibits the growth of bacteria, mold or fungi.

HandPunch Main Board for HP-1000

Schlage Handpunch 1000 E Manual

Replacement Part HandPunch Main Board for HP-1000

Refurbished HandPunch Main Board for HP-1000

Replacement Part HandPunch Main Board for HP-1000

HandPunch Top Panel Assembly for HP-1000

Replacement Part HandPunch Top Panel Assembly for HP-1000

Handpunch 3000 Manual

Refurbished HandPunch Top Panel Assembly for HP-1000

Replacement Part HandPunch Top Panel Assembly for HP-1000

3.4 derivative of e^f(x) and ln (f(x))ap calculus. 3.4 Derivative Rules Log and Exponential Functions Notes 3.4 Key. AP Calculus AB - Worksheet 27 Derivatives of ln and e Know the following theorems: 1. Math AP®︎/College Calculus AB Differentiation: definition and basic derivative rules Derivatives of cos(x), sin(x), 𝑒ˣ, and ln(x) Derivatives of 𝑒ˣ and ln(x) AP.CALC: FUN‑3 (EU), FUN‑3.A (LO), FUN‑3.A.4 (EK). 3.4.3 Apply rates of change to displacement, velocity, and acceleration of an object moving along a straight line. 3.4.4 Predict the future population from the present value and the population growth rate. 3.4.5 Use derivatives to calculate marginal cost and revenue in a business situation.

HandPunch HP-1000 Overlay

Schlage HandPunch HP-1000 Overlay. Simply change your hand reader's overlay to keep its new look.

Rubber Keypad for Schlage HandPunch

The rubber keypad for HandPunch F-Series time clocks constructed from strong lightweight silicon rubber seals against outside elements

HandPunch Back Plate Wall Mounting Bracket for HandPunch Terminals

HandPunch back plate for all F-series Schlage HandPunch terminals. Many in stock, call or order online!

Refurbished HandPunch Back Plate Wall Mounting Bracket for HandPunch Terminals

Handpunch 1000

HandPunch back plate for all F-series Schlage HandPunch terminals. Many in stock, call or order online!
