  1. Fan Header On Motherboard
  • BIOSTAR has announced the release of Windows 7 support for its latest Intel and AMD motherboards including the A10N-8800E and H310MHG. Windows 7 remains to be the second most-used Windows operating system for many home, office, schools and government organizations, PC’s still running this operating system can continue to do so with BIOSTAR’s latest Intel and AMD platform motherboards.
  • Each fan can be customized to operate at different speeds according to any defined temperature source input (except the CPU fan). Monitor components such as the clocks and processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behavior; these are the possibilities of the System.

About CPU Fan Header

To learn what does CPU OPT mean, first of all, you need to know what is a CPU fan header.

Fan Headers On Motherboard Download Freebackstage

According to the answer on Quora, most computers have a CPU and a heatsink mounted on top of the CPU with a fan. A CPU fan header is where you plug the fan. The CPU fan header is important for it can detect whether your fan is working or not. If it detects the fan isn’t running or is not working properly, it will close the system or stop the system from starting to protect the computer from overheating.

Fancasee 4-Pin PWM Fan Power Supply Cable 1 to 5 Splitter 5 Way PC Case Internal Motherboard Fan Power Extension Cable Cord Wire for ATX Computer Case 4-Pin and 3-Pin Cooling Fans (13 inch, Black) 4.7 out of 5 stars 1,109. 3 case fans 2 fan headers on motherboard I have NZXT Source 220 ATX Mid Tower Case and Gigabyte GA-H170M-D3H Micro ATX LGA1151 Motherboard only 2 fan headers and 3 case fans:( hELP ME Showing 1-8 of 8 comments ☥ - CJ - May 7, 2016 @ 2:53pm You can find a fan splitter cable, practically at any website carrying such things.

CPU fan not spinning? Check the 4 solutions in this tutorial to fix CPU fan not running problem.

What Is CPU OPT?

CPU opt meaning is CPU optional. It is a header that is used to connect some type of wiring for a liquid cooling system. Once connected, you are able to control the speed of the fan from the motherboard.

Most gaming motherboards are equipped with such CPU OPT for controlling the heat sink speed. when you aren’t using the PC for heavy load, you can reduce the fan speed so as to reduce the noise of your system.

Headers

Some heatsinks may pair with 2 fans or may have clips on both sides. In such a situation, one fan pushes cool air into the fins while the other fan pulls hot air out.

In general, CPU OPT is an additional CPU fan header. Since it is “additional”, it is not necessary and the system can start normally without working with CPU_OPT. that is to say, CPU OPT can’t prevent the system from booting if there is a problem. Yet, it can warn you about problems.

Motherboard

Is your HP laptop fan always running and making grinding noise? The post will show you how to fix the issue of HP laptop fan noise in Windows 10.

CPU Fan vs CPU OPT

Both CPU fan header and CPU OPT fan connecter are heatsink headers for connecting the fans of radiators on the motherboard. The difference is that the CPU fan header can detect fan problems and protect the system from overheating by preventing it from booting. Dmg events abu dhabi. While the CPU-OPT and only detect and warn about issues; it cannot take actions to deal with the problems.

Case Fan

Fan Headers On Motherboard Download Freebackstage

As the name indicates, a case fan is a kind of fan used to cool the case or enclosure of the computer host. There are other names for this type of cooler like SYS fan. As for the brand Asus, it calls it a chassis fan or CHA-FAN.

Similar to CPU OPT, a case fan can inform you if there is a problem with the fan, but can’t protect the system from overheating by stopping it from booting up.

Tip: Besides the fan headers mentioned above, there are also some other fan headers including AIO_PUMP, W_PUMP+, and H_AMP.
Headers

Also read: Introduction to Computer Fan Including Applications

Can I Use CPU OPT for Case Fan?

CPU fan header, CPU OPT, and SYS fan header, if all of them are 4 pin fan headers, the motherboard, and in turn the BIOS and the OS, can control the fans’ speed. therefore, theoretically, you can connect the case fan or one of the case fans to the CPU OPT without a problem.

However, if you connect your case fan with the CPU opt header, the speed of the case fan will increase dramatically when the CPU gets hot, just like the heatsink/CPU fan connected to the CPU_FAN header will do. And, when the CPU cools down, the case will slow down.

While if you connect the case fan into the SYS_FAN header, it will change its speed accordingly by the signal coming from the thermal sensor or some software controlled by the BIOS or the OS.

Fan Header On Motherboard
